We can according to customer necessary to supply closed with Pantone standard spot color ink.
Model name :
SNT Spot Color InkOrder Quantity(MOQ) :
1KGPayment :
T/T Or L/CProduct Origin :
Made In ChinaColor :
Pantone Standard request colorShipping Port :
Fuzhou of ChinaLead Time :
According to order quantity.If order more than 10 tons it should be take 35 days to producePackage Weight :
1KG Per Can,12 KGS Per Carton1.Introduction
Many manufacturing companies use PMS colors located on various Pantone Color Charts to describe and communicate hues of color, known as the Pantone Matching System (PMS). On each Pantone PMS color chip is the "recipe" to mix inks for each particular PMS ink color. The Pantone Ink Charts are available printed on both coated and uncoated paper stock, as the paper finishes cause significant color variation, not to the hues as much as their color intensity. Matte paper Pantone Color Guides are also Available.
We can provide customers with a variety of spot color services, can deploy a variety of colors to meet different requirements from different customers . Our spot color ink with stable color, fast drying, bright light, suitable for all kinds of paper printing.
2.Application
Specifying Pantone Colors for Commercial (Offset) Printing is very Important.
The Pantone Matching System is used when there is a need for a very specific color, which will be identical no matter where it is printed. Using the universal Pantone system, you can find the exact color that you want to use in your design, and we will use that ink formula to match the color.
3.Ink's Property
COLOR | white | Medium | O.P.Varnish | Matt Varnish | |
DM | 36 - 38 | 35 - 37 | 39 - 42 | 39 - 41 | |
TACK | 8.5 - 9.0 | 8.0 - 8.5 | 8.0 - 8.5 | 3.0 - 4.0 | |
GLOSS(60°) | 55 ± 5 | 50 ± 5 | 70 ± 5 | 25 ± 5 | |
PARTICLE SIZE | Below 15㎛ | Below 15㎛ | Below 15㎛ | Below 15㎛ | |
DRYING TIME | PAPER | Below 10Hr | Below 10Hr | Below 10Hr | Below 10Hr |
SKINNING | Over 24Hr | Over 24Hr | Over 24Hr | Over 24Hr | |
RUB REISTANT | 3.0(5Excel - 1Poor) | 3.0(5Excel - 1Poor) | 3.0(5Excel - 1Poor) | 3.0.(5Excel - 1Poor) |
COLOR | Yellow C | Yellow 012C | Orange 021C | Bronze Red | |
DM | 36 - 38 | 36 - 38 | 33 - 35 | 34 - 36 | |
TACK | 7.0 - 7.5 | 7.0 - 7.5 | 8.0 - 8.5 | 7.5 - 8.0 | |
GLOSS(60°) | 60 ± 5 | 60 ± 5 | 60 ± 5 | 55 ± 5 | |
PARTICLE SIZE | Below 15㎛ | Below 15㎛ | Below 15㎛ | Below 15㎛ | |
DRYING TIME | PAPER | Below 10Hr | Below 10Hr | Below 10Hr | Below 10Hr |
SKINNING | Over 24Hr | Over 24Hr | Over 24Hr | Over 24Hr | |
RUB REISTANT | 3.0(5Excel - 1Poor) | 3.0(5Excel - 1Poor) | 3.0(5Excel - 1Poor) | 3.0.(5Excel - 1Poor) |
COLOR | Warm Red | Red 032C | Rubine red | Rhodamine red | |
DM | 34 - 36 | 35 - 37 | 35 - 37 | 34 - 36 | |
TACK | 7.0 - 8.0 | 7.5 - 8.0 | 7.0 - 7.5 | 8.0 - 8.5 | |
GLOSS(60°) | 60 ± 5 | 55 ± 5 | 55 ± 5 | 55 ± 5 | |
PARTICLE SIZE | Below 15㎛ | Below 15㎛ | Below 15㎛ | Below 15㎛ | |
DRYING TIME | PAPER | Below 10Hr | Below 10Hr | Below 10Hr | Below 10Hr |
SKINNING | Over 24Hr | Over 24Hr | Over 24Hr | Over 24Hr | |
RUB REISTANT | 3.0(5Excel - 1Poor) | 3.0(5Excel - 1Poor) | 3.0(5Excel - 1Poor) | 3.0.(5Excel - 1Poor) |
COLOR | Purple | Violet | Blue 072C | Reflex Blue | |
DM | 35 - 37 | 33 - 35 | 33 - 35 | 35 - 37 | |
TACK | 8.0 - 8.5 | 9.0 - 9.5 | 8.5 - 9.0 | 8.0 - 8.5 | |
GLOSS(60°) | 60 ± 5 | 60 ± 5 | 60 ± 5 | 55 ± 5 | |
PARTICLE SIZE | Below 15㎛ | Below 15㎛ | Below 15㎛ | Below 15㎛ | |
DRYING TIME | PAPER | Below 10Hr | Below 10Hr | Below 10Hr | Below 10Hr |
SKINNING | Over 24Hr | Over 24Hr | Over 24Hr | Over 24Hr | |
RUB REISTANT | 3.0(5Excel - 1Poor) | 3.0(5Excel - 1Poor) | 3.0(5Excel - 1Poor) | 3.0.(5Excel - 1Poor) |
COLOR | Green | Special black | |
DM | 33 - 35 | 35 - 37 | |
TACK | 9.0 - 9.5 | 7.5 - 8.0 | |
GLOSS(60°) | 50 ± 5 | 60 ± 5 | |
PARTICLE SIZE | Below 15㎛ | Below 15㎛ | |
DRYING TIME | PAPER | Below 10Hr | Below 10Hr |
SKINNING | Over 24Hr | Over 24Hr | |
RUB REISTANT | 3.0(5Excel - 1Poor) | 3.0(5Excel - 1Poor) |
DM : Measured by Spreadmeter(60sec/25℃)
TACK: Measured by Ink-o-meter(60sec/400rpm, 32℃)
DENSITY:X-Rite 528 (D50/2°Status T,White Backing)
SET TIME : Measured by Setting tester(120g/㎡, INK 0.075㏄,1/4roll)
GLOSS : Measured by Glossmeter(60°)
PARTICLE SIZE : Measured by Grinding gauge(㎛)
RUB REISTANT : Measurde by Rub tester
4.Packing
5.Logistic
